Product Description
1. PVC Electric Conduit Pipe Making Machine/extrusion lineis our main product and have been exported to many different
countries. Under our technical supports and formula of material helping, many customers save their cost and take a good
occupancy in their local market.
2. PVC Electric Conduit Pipe Making Machine/extrusion line is mainly used in the manufacture of plastic PVC pipes with various
diameters and wall thickness used in the industries such as agricultural and constructional plumbing, cable laying,drain water
etc
3. PVC Electric Conduit Pipe Making Machine/extrusion line is composed of conical twin-screw extruder, vacuum calibration tank,
haul-off, cutter and stake etc. The extruder and haul-off adopt imported AC frequency control device, vacuum pump and haul-off
motors adopt high-quality products.
Characteristics of PVC Electric Conduit Pipe Making Machine/extrusion line:
1. one die double out or four out, it greatly increase the productivity, meantime, it reduces the cost of machine, power
consumption, save space of workshop
2. Speed of extruding, haul off machine are controlled by variable frequency inverter, stepless adjusting speed and save power
consumption
3. Water cooling tank are made of high qulity 304 stainless steel, no rusty, longer lifetime.
4. Temperature controlled by intelligent temperature controller, high precision, automatic control, save labor and easy to operate.
PVC Electric Conduit Pipe Making Machine/extrusion line:
Product Parameters
PVC two/four cavity conduit Pipe Production Line | Model | Pipe Diameter | Output | Max Speed | Motor | Total Length |
| SJSZ-51/105 | 16-50 mm | 80-120 kg/h | 6 m / min*2 | 22 kw | 22m |
| SJSZ-65/132 | 50 - 110 mm | 200-300kg/h | 8m/min*2 | 537kw | 23m |
Detailed Photos
Certifications
After Sales Service
1. After the machines are finished, the seller will test all machines before shipment. If the buyer can not come to test the machine,
we will test the machines and send the sample to buyer.
2..After shipment, the seller will send one or two technicians to the buyer's factory to help the buyer install the machine and train
workers for buyer. 3. We will supply all electricity drawing, machine installation drawing.
4. When make shipment, we will put some spare electricity parts for free, like the barrel hearers, thermcouples, breakers, relays,
and other items which is easier broken.
