38CrMoALA Material Twin Conical Screw Extruder for Two Cavity PVC Pipe Production Line

Condition : New

Plastic Processed : PVC

Application : PIPE

Screw Design : Double-screw

Twin Screw Type : Counter-rotating conical Twin-screw

Screw Material : 38CrMoALA

Screw diameter (mm) : 51

Screw L/D Ratio : 28:1

Screw Speed (rpm) : 45 rpm

Showroom Location : Egypt, Turkey, Italy, Brazil, Peru, Pakistan, India, Russia

Place of Origin : Shandong, China

Brand Name : Changyue

Voltage : 380V

Dimension(L*W*H) : 28000mm/2500mm/2800mm

Power (kW) : 37

Weight : 8500 KG

Warranty : 1 Year

Key Selling Points : High Quality

Applicable Industries : Manufacturing Plant

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Engine, Gearbox, Screw

Machinery Test Report : Provided

Marketing Type : Ordinary Product

Port : Qingdao

Supply Ability : 10 Set/Sets per Month

Price : $30,000.00/sets >=1 sets

Packaging Details : Export Film Packing / According To Customer

Delivery Time : 15 Days (1 - 1 Pieces) To Be Negotiated ( > 1 Pieces)

Contact Now

Products Description
1. Process flow:
PVC powder + additive → mixing → spiral auto loader → twin screw extruder → mould → vacuum calibration tank →
haul off machine →laser pinter cutting machine → stacker or automatic belling machine

2.Conical twin screw extruder

3.Die head. Due to the diameter, it can be single, double and four die head

4.Vacuum tank: due to diameter, it can be designing of single, double vacuum chambers

5.Haul-offs: due to diameter, it can be designing of double, three, four, six, eight caterpillars

6.Cutter: due to diameter, it can be designing of saw cutter or planetary cutter

7.stacker or automatic belling machine

8. laser printer: print the company name or brand name on pipe
Specification
item
value
Condition
New
Plastic Processed
PVC
Application
PIPE
Screw Design
Double-screw
Counter-rotating conical Twin-screw
Screw Material
38CrMoALA
Screw diameter (mm)
51
Screw L/D Ratio
28:1
Screw Speed (rpm)
45rpm
Showroom Location
Egypt, Turkey, Italy, Brazil, Peru, Pakistan, India, Russia
Place of Origin
China
Shandong
Brand Name
Changyue
Voltage
380V
Dimension(L*W*H)
28000mm/2500mm/2800mm
Power (kW)
37
Weight
8500KG
Warranty
1 Year
Key Selling Points
High Quality
Applicable Industries
Manufacturing Plant
Video outgoing-inspection
Provided
Warranty of core components
1 Year
Core Components
Motor, Engine, Gearbox, Screw
Machinery Test Report
Provided
Marketing Type
Ordinary Product
Product Paramenters
model
pipe diameter
output
max speed
motor
total length
SJSZ-65/132
20-63mm
180-250kg/h
6m/min*2
30kw
20m
SJSZ-80/156
50-110mm
300-400kg/h
8m/min*2
55kw
22m
